Colleagues,
If strategic analysis areas of interest could be represented by a Venn diagram,
one of the most interesting areas of overlap would, oddly enough, be in
electrical grids. I've written about grid structures and problems before,
but the subject is worth thinking about at length. The average grid in
Canada and the US these days accepts power generated both from traditional
(thermal, hydroelectric, and nuclear) and 'green' (wind, solar, biomass and so
forth) sources. Thermal generation from coal, oil, and natural gas evokes
Middle Eastern nations, Islamism, terrorism, environmental damage, sulphur
dioxide emissions, acid rain, China's exploding power demand (and its equally
exploding coal-fired generating capacity), health problems, the 'Asian Brown
Cloud', oil tankers, oil spills, drilling moratoria, pipelines to the US,
pipelines to the west coast, wildlife preserves, aquifers, and a host of other
topics. Hydroelectric generation engages questions of rainfall and
snowfall, melt dates, water levels, water usage, droughts, irrigation,
sedimentation, critical infrastructure protection, species preservation, and
massive civil engineering projects. Nuclear power engages proliferation
concerns, supplies of uranium ore, enrichment technologies, Iran, nuclear
weapons, nuclear wastes, nuclear waste transport and storage, regulatory
issues, more terrorism, earthquakes, tsunamis, leaks, Three-Mile Island,
Chernobyl, arms control, arms reduction, pre-emptive strikes, Russian
collaboration, and (once again) the Middle East. And 'green' energy
sources involve so many ancillary considerations that there's no point trying
to list them here.
This is why it's fascinating to take a look at
where all of these factors come together - in the massive minute-by-minute
balancing act that's necessary to keep a large electrical grid system operating
in the face of complex and shifting loads, supplies, and environmental
factors. Forbes recently published an article looking at how the Bonneville
Power Administration, which manages water flow on the Colorado River and powers
a large part of the US Pacific Northwest, manages to keep the power supply
available and balanced.
The article can be found here:
http://www.forbes.com/sites/jonbruner/2011/10/20/the-high-stakes-math-behind-the-wests-greatest-river/
It's a great example of engineering hoo-rah (the author had me at
"five-ton circuit breaker"), and worth a read for that reason alone;
but from a strategic analysis perspective, one of the graphics in particular
caught my eye. It was this one:
That's one week in the life of the Bonneville
Power Administration (BPA - not to be confused with
bis-phenol A,
the chemical that's had legions of nervous nellies chucking their
plastic kettles out for the past decade). It's the week that took
place exactly one month ago, to be precise [
ACTUALLY, 14-21 OCTOBER 2011 - ed.).
That graph tells us a whole
lot of really important things. The first thing it tells us is that
electrical demand - the scarlet line - is actually incredibly
predictable. There's a fascinating lesson here. At its most basic,
nuclear fission is random chance; but if you assemble enough, say, uranium
atoms in one place, they demonstrate statistically predictable behaviour.
Same with people. You or I can decide whether or not to flip a light switch
on or off; it's a matter of personal choice, and your choices (and mine) may be
utterly unpredictable. But if you assemble millions of people, their
behaviour - for example, in consuming electricity - starts to become
statistically very predictable. As the scarlet line shows, there are
predictable demand surges in the morning, as people are preparing to go to
work, and in the evening, as they make dinner and perform other chores; and
there are predictable declines in demand: a shallow one at lunch time, and a
much larger one over night. Moreover, those demands don't vary greatly
from workday to weekend. If it weren't for the day notations on that
chart, you'd be hard-pressed to tell Friday from Saturday. It's easier to
make out Monday and Tuesday by the early morning peaks - although it's
interesting to note how that peak, which starts off high on Monday, declines
daily through the week, until the Friday morning peak is within a few
percentage points of the Saturday morning peak. I guess that's not really
surprising, is it?
The brownish-red line is interesting,
too. That's thermal generation, and most of the time it's remarkably
steady. This is because thermal power plants, all of which are basically
steam turbines, operate most efficiently when they operate at continuous
output. Boilers, after all, have to be brought up to operating
temperature, and take time to cool down. Some thermal plants - small,
gas-fired turbine plants, for example, which are basically jet engines hooked
up to generators - can start up and ramp down quickly, but doing so tends
to be costly in terms of fuel. Imagine powering your house by generating
electricity from a jet engine; actually, those of us who worked in ADATS
units don't need to imagine it, because each ADATS vehicle had a jet engine
hanging off the front of it, and burned 1300 litres of diesel every 24 hours
just to keep the lights on. It's effective, but it's not
cost-effective, to start up and stop in response to unpredictable shifts in demand.
As a rule, thermal plants work most efficiently, and get the most electrical
power out of the heat content of their fuel, when they maintain continuous,
stable output.
The blue line - hydro plants - are the exact
opposite of thermal plants. Hydro power is pretty much the most efficient
source of generation on Earth. It's essentially solar power, with the
motive force for electrical generation provided by potential energy brought to us courtesy evaporation, condensation
and precipitation. The water is stored behind dams, and can be released
through turbines to generate kinetic energy (in the form of spinning turbines driving generators to push electrons through a wire) pretty much at will. Hydro power is extremely responsive, able to ramp up and
down in a matter of minutes to respond to changes in demand and supply.
The green line is the wild card in the
deck. That's wind power. The BPA has about 3500 MW of wind power
installed, roughly equivalent to about 2000 large turbines. That green
line tells you everything you need to know about the complexities that
government-subsidized wind farms have introduced into the grid management
equation. On the 14th and 15th of last month, the BPA's wind turbines
were basically flatlined. On the 16th, there was a brief spike in
production. The turbines put out a little bit of power - about a quarter
of the installed capacity, which is par for the course for wind turbines - over
the night of 17-18 October. And then, on the afternoon of the 19th, Gaia
cut loose and the wind productivity soared.
Look what happened to the rest of the
grid. In the space of about an hour, electrical generation from wind
turbines went from nothing to about 85% of nameplate capacity - and in that same
hour, demand actually fell, by about 200 MW. Thermal plants were running
as usual, providing baseline power, and hydro plants, being the most flexible,
were going through their daily double-hump routine to take care of the morning
and afternoon demand surges. Just before lunch, when demand was falling,
wind power production exploded, dumping 3000 unneeded MW into the
grid. Hydro generators had to be shut down as quickly as possible to
avoid catastrophic oversupply (which can trip circuit breakers and cause wide
area power outages); and because that wasn't enough to stem the flow of power,
even thermal plant output had to be scaled back, greatly reducing efficiency. And then, five
hours later, as the wind died back down to nothing, hydro and thermal plants
had to be brought back on line.
The problem is that while we can predict demand
with reasonable accuracy, we never know when the wind's going to blow, or how
hard, and when it's going to stop blowing. This means that wind
power can never be a
replacement power source; it can only be a
supplemental
power source. And because it's entirely unreliable, you cannot afford to
take a single MW of conventional production off line unless you feel like
explaining to Missus Miggins why she can't boil water for tea. Moreover,
because wind power is an unpredictable, supplemental power source, your grid
system has to be flexible enough to be able to accept unpredictable injections
of power - which means that your conventional production capacity has to be rapidly
scalable both up and down. As the graph and the BPA experience
demonstrates, this is a costly and technically challenging problem, principally because power generation has always been designed to operate continuously, because that's what's most efficient.
It's
funny, isn't it, how whenever policy and ideology bump up against the real world, the
resulting problems are ALWAYS 'costly and technically challenging'?
And if you think managing the northwest power grid
is complex now, wait until 2013, when BPA is supposed to have twice as much
wind capacity installed - 6000 MW, if current plans don't run headlong into
looming fiscal realities. If 6000 MW of wind power were to suddenly come on line
at a time of low demand, the rest of the conventional generators would have to
have the capability to drop to virtually zero output in a matter of
moments - and to then come back on line as soon as the wind died down. If you need a visual image, think about a Nascar race with 50 competitors
on the track, moving at full speed, inches away from each other, and a rule that requires the marshal to always have between 49 and 51 cars on the track, no more, and no less. Now,
without warning, 25 more cars come in from an injector lane, moving at full
speed, and the race marshal has to get 25 of the original competitors off the
track in a matter of seconds, without letting anybody bang into each
other. And then think about what happens if the new arrivals suddenly off-ramp without warning, and the marshal has to feed an unpredictable number of the original drivers back onto track, ensuring that the total number of cars never gets outside of the 49-51 mandatory total.
If that sounds impossible consider the fact that it's far too restrictive
an analogy, because the energy of the moving electrons that
the BPA grid handles every minute is roughly equal to the amount of kinetic
energy of about 21,000 stock cars moving at 200 km/hr.
I'd say that's quite a balancing act.
What's the strategic analysis angle in all
this? Well, many of the proponents of wind power are selling it not
only because of its supposed environmental advantages (on that point,
you might want to google "China cancer city"), but
as a solution to the problem of "energy dependence"
for the US. Really? Only 18% of the petroleum
imported by the US last year came from the Persian Gulf (25% came from
Canada); but 75% of the world's supply of neodymium-iron-boron magnets
(the key enabling technology for the newest generation of direct-drive
wind turbines) and 60% of the world's supply of samarium-cobalt magnets (the
key enabling technology for older, geared wind turbines) comes from China
- which also, not at all coincidentally, produces 97% of the world's supply of
neodymium and samarium.
It's almost as if the US government asked
itself whether it wanted to be 18% dependent on Saudi Arabia for its
energy needs, or 97% dependent on China, and settled on the latter.
Come to think of it, that's kind of a balancing act too, wouldn't you say?
Cheers,
//Don//
